| TRAVEL |
|---|
| Longitudinal-X axis | mm | 760 | 1000 |
| Cross-Y axis | mm | 500 | 500 |
| Vertical-Z axis | mm | 520 / 700 (opt.) | 520 / 700 (opt.) |
| TABLE |
|---|
| Table size | mm | 1372 x 305 | 1524 x 406 |
| T-slot | mm | 16 x #3 | 16 x #4 |
| Max. loading capacity | kgs | 600 | 800 |
| SPINDLE |
|---|
| Spindle taper | - | BT#40 / CAT40 | BT#40 / CAT40 |
| Spindle speed | rpm | 8000 / 10000, 12000 (opt.) | 8000 / 10000, 12000 (opt.) |
| FEED |
|---|
| Feed rate | mm/min. | 1-3000 | 1-3000 |
| Rapid traverse rate | mm/min. | 5000 | 5000 |
| Ballscrew | mm | φ32 x 5P x C5 | φ32 x 5P x C5 |
| MOTORS |
|---|
| Spindle drive motor | kw | 5.5 / 7.5 | 5.5 / 7.5 |
| X,Y,Z axis servo motor | kw | 1 | 1 |
| Coolant pump motor | HP | 1/8 | 1/8 |
| TOOL CHANGER |
|---|
| Tool selection | - | Bi-directional shortest route | Bi-directional shortest route |
| Max. tool diameter * length (adjacent tool) | mm | 80 x 250 | 80 x 250 |
| Max. tool weight | kgs | 7 | 7 |
| Tool shank | - | BT#40 / CAT40 | BT#40 / CAT40 |
| ATC- Armless type | - | 16 / 20 tools | 16 / 20 tools |
| ATC- Arm type | - | 20 tools | 20 tools |
| Semi splash guard | - | Yes (opt.) | Yes (opt.) |
| Full splash guard | - | Yes | Yes |
| MACHINE DIMENSIONS |
|---|
| Machine overall height | mm | 2400 / 2600 (opt.) | 2400 / 2600 (opt.) |
| Machine floor space | mm | 2450 x 2000 | 2700 x 2000 |
| Machine net weight | kgs | 3600 | 3800 |
| CNC Controller | - | Fanuc, Mitsubishi, Fagor, Syntec | Fanuc, Mitsubishi, Fagor, Syntec |
