MILLING MACHINE

EM-1460B / 1660B / 2065B

Features

  1. Double nut-precision ball screw for X, Y and Z-axis. It keeps high precision and durability life of the machine.
  2. X, Y, Z axis employ DC servo motors, providing variable feed speed change. Rapid feed rate offerss 2-3 times higher efficiency than frequency inverter controlled motor. Greater torque output at low-speed running. It can be fitted with an optional MPG hand wheel.
  3. The automatic lubrication system adjusts the timing and flow to provide excellent lubricating oil onto all the sliding ways. When lubricant reaches control-limited, it rings and to remind you to fill oil.
  4. Spindle head can change to variable head.
  5. Spindle nose of spindle head can change to NT50#.
  6. Available to equip with H type powerful horizontal cutting mechanism. Featuring gear head drive, servo motor drive on vertical feed, and hand wheel control for added operational convenience.

Specification

ITEMUNITEM-1460BEM-1660BEM-2065B
TRAVEL
Longitudinal travel-X axismm140016002000
Cross travel-Y axismm600650650
Vertical travel-Z axismm700 / 800 / 900 / 1000700 / 800 / 900 / 1000700 / 800 / 900 / 1000
TABLE
Table sizemm1702 x 5101900 x 5102450 x 580
T-slotmm4 x 18 x 804 x 18 x 805 x 18 x 95
Table loadkgs100010001500
Speed feed (X,Y,Z axis)mm/min10-300010-300010-3000
Rapid feed (X,Y,Z axis)mm/min480048004800
SPINDLE
Spindle taper-NT#40 / BT#40NT#40 / BT#40NT#40 / BT#40
Quill diametermmφ110φ110φ110
Quill travelmm140140140
Spindle speedrpm/min65-3580 (16-step) or 85-3600 Variable (opt.)65-3580 (16-step) or 85-3600 Variable (opt.)65-3580 (16-step) or 85-3600 Variable (opt.)
Quill feed speedmm/Rev0.035, 0.07, 0.140.035, 0.07, 0.140.035, 0.07, 0.14
Vertical head swiveling angle (R&L)-45°45°45°
Spindle nose to tablemm100-800 / 900 / 1000 / 1100100-800 / 900 / 1000 / 1100100-800 / 900 / 1000 / 1100
Spindle center to columnmm650650650
MOTOR
Spindle motormm5HPx2P / 4P or 7.5HPx2P / 4P (opt.)5HPx2P / 4P or 7.5HPx2P / 4P (opt.)5HPx2P / 4P or 7.5HPx2P / 4P (opt.)
X,Y,Z axis servo motorsNm4.5 Nm4.5 Nm4.5 Nm
Coolant pumpHP1/8 HP1/8 HP1/8 HP
Net weightkgs450047005700
